Bike carrier comparison

Payload

Do you have a heavy bike or a weighty pedelec? What is the load capacity of your car ...?

Foldable straps Platform carrier

Properties

Do you need an extension or a special e-bike suitability ...?

Foldable straps Platform carrier

Equipment

Would you like a loading aid, additional gripping arms, or a bag for your carrier ...?

Foldable straps Platform carrier

Bicycle rack for the trailer coupling

Foldable straps

Foldable straps Genio Pro Advanced STRADA Vario 2 STRADA Vario 3
open (wide / high / deep) mm 1240 / 705 / 650 1160 / 760 / 620 1160 / 710 / 760
folded (wide / high / deep) mm 385 / 705 / 650 640 / 420 / 660 640 / 480 / 760
Distance between rails in mm 210 190 190
Tire sizes in inches up to 4 inches up to 2.4 inches * up to 2.4 inches *

* Snap band set available for fat tires.

LOADING

Foldable straps Genio Pro Advanced STRADA Vario 2 STRADA Vario 3
Dead weight in kg 21,4 17,5 21,2
max.load in kg 60 57,5 63,8
Payload 1st rail in kg 30 30 30
Payload 2nd rail in kg 30 30 30
Payload 3rd rail in kg – – 17,5
Payload extension 17,5 – –
Payload with extension 65 – –

Please note the vehicle manufacturer's information on the maximum payload of the trailer coupling.

PROPERTIES

Foldable straps Genio Pro Advanced STRADA Vario 2 STRADA Vario 3
Bicycle spaces 2 2 3
expandable 2 + 1 – –
E-bike suitability very good very good very good
Frame Protection and and and
Gripping arms can be freely positioned and and and
Grab arms removable and and and
Lockable gripping arms and and and
Lockable bike and and and
Lockable carrier and and and
foldable with load far Well very far
tail lights integrated integrated integrated
Plug connection 13-pin 13-pin 13-pin
Model number 022 780 022 750 022 751

EQUIPMENT

Foldable straps Genio Pro Advanced STRADA Vario 2 STRADA Vario 3
Extension set 022 781 – –
Foldable loading ramp 022 782 022 742 022 742
Loading ramp – 022 741 022 741
bag 022 783 022 760 022 761
zusätzl. Greifarme 022 633 022 633 022 633
Spacers and and and
One-Key-System and and and
Snap band set up to 3.0 not necessary 022 730 022 730
Snap band set up to 4.0 not necessary 022 735 022 735

Bicycle rack for the trailer coupling

platform carrier

Platform carrier STRADA Evo 2 STRADA Evo 3 STRADA Sport 2 STRADA Sport 3 STRADA E-Bike STRADA E-Bike XL STRADA DL 2 STRADA DL 3 STRADA Trail 2
wide / high / deep 1080 / 330 / 590 1080 / 280 / 735 1000 / 200 / 590 1000 / 200 / 720 1000 / 200 / 590 1200 / 200 / 590 1000 / 250 / 560 1000 / 250 / 720 1100 / 250 / 675
for frame diameter 25 to 80 mm 25 to 80 mm 25 to 80 mm 25 to 80 mm 25 to 80 mm 25 to 80 mm 25 to 80 mm 25 to 80 mm 25 to 80 mm
Distance between rails in mm 190 190 190 180 230 230 180 180 230
for tire sizes up to 2.4 inches * up to 2.4 inches * up to 2.4 inches * up to 2.4 inches * up to 2.4 inches * up to 2.4 inches * up to 2.4 inches * up to 2.4 inches * up to 3.0 inches*
Retaining bracket inclinable inclinable inclinable inclinable inclinable inclinable inclinable inclinable inclinable

* Accessories: locking strap set for fat tires.

LOADING

Platform carrier STRADA Evo 2 STRADA Evo 3 STRADA Sport 2 STRADA Sport 3 STRADA E-Bike STRADA E-Bike XL STRADA DL 2 STRADA DL 3 STRADA Trail 2
Dead weight in kg 16,8 20,1 14,9 18,1 14,9 15,8 12,5 14,5 17,5
max.load in kg 60 66 60 66,9 60 59,2 47 45 60
Payload 1st rail in kg 30 30 30 30 30 30 23,5 23,5 30
Payload 2nd rail in kg 30 30 30 30 30 30 23,5 23,5 30
Payload 3rd rail in kg – 30 – 30 – – – 23,5 -
Payload extension in kg 15 15 17 17 17 17 17 17 17,5
max.load with extension 60 66 67,9 68 67,9 67 45 63 65

Please note the vehicle manufacturer's information on the maximum payload of the trailer coupling.

PROPERTIES

Platform carrier STRADA Evo 2 STRADA Evo 3 STRADA Sport 2 STRADA Sport 3 STRADA E-Bike STRADA E-Bike XL STRADA DL 2 STRADA DL 3 STRADA Trail 2
Bicycle spaces 2 3 2 3 2 2 2 3 2
expandable 2 + 1 3 + 1 2 + 1 3 + 1 2 + 1 2 + 1 2 + 1 3 + 1 2 + 1
E-bike suitability very good very good Well Well outstanding outstanding suitable suitable suitable
Frame Protection yes yes yes yes yes yes yes yes yes
Gripping arms can be freely positioned yes yes yes yes yes yes yes yes yes
Grab arms removable yes yes no no no no no no no
Lockable gripping arms yes yes yes yes yes yes yes yes yes
Lockable bike yes yes yes yes yes yes yes yes yes
foldable with load Well far Well far Well Well Well Well far
tail lights integrated integrated integrated integrated integrated integrated integrated integrated integrated
Plug connection 13-pin 13-pin 13-pin 13-pin 13-pin 13-pin 13-pin 13-pin 13-pin
Model number 022 700 022 701 022 684 022 685 022 686 022 696 022 600 022 601 022 790

EQUIPMENT

Platform carrier STRADA Evo 2 STRADA Evo 3 STRADA Sport 2 STRADA Sport 3 STRADA E-Bike STRADA E-Bike XL STRADA DL 2 STRADA DL 3 STRADA Trail 2
Extension set 022 710 022 711 022 610 022 624 022 624 022 624 022 610 022 611 022 792
Foldable loading ramp 022 742 022 742 022 742 022 742 022 742 022 742 022 742 022 742 022 782
Loading ramp 022 741 022 741 022 635 022 635 022 635 022 635 022 635 022 635 022 741
zusätzl. Greifarme 022 633 022 633 022 633 022 633 022 633 022 633 022 633 022 633 022 633
additional Spacers in 3 lengths in 3 lengths in 3 lengths in 3 lengths in 3 lengths in 3 lengths in 3 lengths in 3 lengths in 3 lengths
One-Key-System possible possible possible possible possible possible possible possible possible
Snap band set up to 3.0 022 730 022 730 022 730 022 730 022 730 022 730 022 730 022 730 022 730
Snap band set up to 4.0 022 735 022 735 022 735 022 735 022 735 022 735 022 735 022 735 022 735
